Floor plan with
Plan details
Room list
No room has been created on this plan.
Object list
| Object name | Quantity |
|---|---|
| Applied lighting | 10 |
| Ceiling lighting | 9 |
| Switch | 9 |
| Push button switch | 3 |
| Two-way switch | 13 |
| Legend | 1 |
| Socket | 30 |
| Optical Terminal socket (fiber) | 1 |
| Roller shutter socket | 7 |
| Cast iron radiator 2350 W (110 W per element) | 4 |
| 1000W electric towel radiator with inertia | 2 |
